Model |
YC-45 |
|
|
Printing width |
Max 450mm A2 |
|
|
Print Head |
Epson XP600 / I1600 / I3200 |
|
|
Print head Quantity |
2 | |
|
Colors |
CMYK+W |
|
|
Resolution |
Max 1080dpi | 2400dpi |
|
| Control System | Honson | |
|
Print Speed |
XP600/I1600 6pass 4.5㎡/h 8pass 3㎡/h |
I3200 6pass 8㎡/h 8pass 6㎡/h |
|
Cleaning |
Automatic |
|
|
Inks type |
Pigment ink |
|
|
Cartridge Capacity |
500ml/Color |
|
|
Heating system |
Pre and Past 2-stage heating |
|
|
Rip software |
Maintop 6.1 *Optional Flexi |
|
|
Interface |
Ethernet Port |
|
|
Operation System |
Win10/win7 |
|
|
Printer Rated Power |
300W |
|
|
Machine Size |
1030*700*530mm |
|
50cm Powder Shaker Machine
Working width
Max 50cm 19.6"
Control functions
Spreading speed,shaking speed,direction
Rated Voltage/Current
220V/10A or 110V/20A
Rated Power
2150W
Basic Functions
Spreading,Shaking,Heating,Cooling, Take-up film
Other Functions
Drying and curing , cold air cooling , automatic sensor-controlled film collection
Machine Dimensions / Net Weight
770*600*730mm / 48kg
Packing Dimensions / Gross Weight
940*740*860mm / 68kg
