1530W Woodworking CNC Router
Model: 1530W
Price:
- Features
- Parameters
- Video
- Download
1, Industrial steel pipe frame, with stable moving, low noise and high precision.
2, Intelligent motion control system, easy use and fast learn operation.
3, Helical rack pinion, plus planetary reducer, ensure the high precision.
4, High torque stepper driver, ensure high precision under high speed.
5, Designed by professional team, advanced structure, simple and generous exterior.
Applicable Fields
Nonmetallic material engraving and cutting, soft metal cutting, solid wood and non-painting door processing, advertising making, mould manufacturing, etc.
Details:
2, Intelligent motion control system, easy use and fast learn operation.
3, Helical rack pinion, plus planetary reducer, ensure the high precision.
4, High torque stepper driver, ensure high precision under high speed.
5, Designed by professional team, advanced structure, simple and generous exterior.
Applicable Fields
Nonmetallic material engraving and cutting, soft metal cutting, solid wood and non-painting door processing, advertising making, mould manufacturing, etc.
Details:
 |
Industrial steel pipe frame, with stable moving,low noise and high precision |
 |
3KW Water Cooling Spindle as standard, available bigger power spindles. Connection type: Collet ER25 Rated voltage: 220V or 380V Rated speed: 24000 rpm Max speed: 24000rpm |
 |
XY axis stepper motors with reduction drive, it is for high load and smoother machining. |
 |
High quality Gear & Rack for X,Y axis, more powerful and faster working. |
 |
Taiwan PMI Linear Square Guide size 20MM linear square guide with double bearing.2 linear rails on each axis. |
 |
Origin NC Studio Control system as standard. PC based NC Studio Controller with more friendly human & machine interface/HMI , fully executed with computer. |
| Model | 1530W |
| Table Size | 1640x3130mm |
| Working Size | 1500x3000x200mm |
| Max .Material Height | 250mm |
| Spindle Power | Water Cooling 3.0kw |
| Speed RPM | 0-24000rpm |
| Driver | Stepper Subdivided |
| Control system | Origin Ncstudio |
| Tool Diameter | Ø3.175,Ø4,Ø6,Ø12.7 |
| Mechanical Structure | Square Steel Pipe |
| Transmission | Ball Screw for Z ; Pully and Rack&Pinion for X,Y |
| Guide Ways | PMI Linear rails |
| Repositioning Accuracy | <0.03mm/300mm |
| MAX. Engraving Speed | 20000mm/min |
| File Format | G Code or HPGL |
| Power Supply | AC220V or 380V,50-60Hz |
| External Form Size | 2400x3560x1650mm |
| Packing Size | 2280x3710x1800mm |
| Net/Gross Weight | 900/1100kg |
| Optional sizes | 1300mmx1300mm,1300mmx1800mm,1500mmx3000mm,2000mmx4000mm |
| Optional parts |
Vacuum bed, Extractor, Tool height sensor, Central Lubricator,hybrid servo system , 4th axis, or bigger power spindle    |
